QA1’s GFT Series stainless steel female rod ends are constructed using a traditional two-piece design which is ideal for use in a range of commercial applications. GFT Series rod ends feature a 300 series stainless steel body and a self-lubricating PTFE liner, making them an excellent choice for use in corrosive environments. Available in both right- or left-hand threads. Stud configurations are also available.
- BALL: 440C Stainless Steel, Heat Treated, Precision Ground, Hard Chrome Plated
- LINER: Self-Lubricating PTFE
- BODY: 300 Series Stainless Steel
Specifications
- Rod End SeriesG Series
- Style/Construction2 Piece Stainless
- Bore0.3125in. or 5/16in.
- Thread DirectionRH
- Thread Size and Pitch5/16in.-24
- Male or Female ThreadFemale
- PTFE Lined?Yes
