QA1's MVF Series carbon steel metric female rod ends with bronze race are generally appropriate for low load, high oscillation applications. These commercial rod ends are protective coated for corrosion resistance and are available with right- or left-hand threads. Flush mount grease fitting is included. Stud variations are available.
- BALL: 52100 Bearing Steel, Heat Treated, Precision Ground, Hard Chrome Plated,
- RACE: Sintered Bronze, Oil impregnated
- BODY: Carbon Steel, Protective Coated for Corrosion Resistance
Specifications
- Rod End SeriesMV Series
- Style/Construction3 Piece Bronze Race
- Bore8mm
- Thread DirectionRH
- Thread Size and PitchM8X1.25
- Male or Female ThreadFemale
- PTFE Lined?No
