HMR10T H Series 3 Piece Alloy Rod End, 5/8in. Bore, 5/8in.-18 RH Male Thread, PTFE Lined

SKU
HMR10T
$39.35
Estimated Shipping Date: Dec 12, 2024
Adding to cart… The item has been added

QA1's HM-T Series alloy/chromoly male rod ends are constructed using a traditional three-piece design and include a self-lubricating PTFE liner. These precision rod ends are heat treated and are available in right- or left-hand threads. Stud configurations are also available.

  • BALL: 52100 Bearing Steel, Heat Treated, Hard Chrome Plated, Precision Ground
  • RACE: Stainless Steel
  • LINER: Self-Lubricating PTFE
  • BODY: Alloy/Chromoly Steel, Heat Treated, Protective Coated for Corrosion Resistance

Specifications

  • Rod End SeriesH Series
  • Style/Construction3 Piece Alloy
  • Bore0.6250in. or 5/8in.
  • Thread DirectionRH
  • Thread Size and Pitch5/8in.-18
  • Male or Female ThreadMale
  • PTFE Lined?Yes
